Logic
When data is generated, all taxable wages are pulled into EmploymentIncome.
If you have non-taxable wages that need to be reported in T4, then you would need to set up on Transaction type setup in Admin tools. You can do this in Admin Tools > Transaction Types.
- UnionDues will pull any Pay wages where the Transaction type has W2Box = 44
- For others, the client will need to add Value in W2 Box. For example: if you want Reimbursements to appear on T4 as Box 10, then you will need to add W2Box = 10 in transaction type setup.
- Box info will pull any one time pay, permanent deductions and Benefits as long as they have value in W2Box.
Report Description
A T4, akin to an American W2, provides employee tax information. The T4_CA offers a detailed look at the tax associated with a supplier's employees.
- Standard Canadian Report - T4A_CA
- T4/T4A Setup for Dental Benefits & Employee Extra for Dental Eligibility Code
Parameters

Parameter Name |
Options |
Explanation |
Supplier |
All Suppliers available |
|
Branch |
All branches available within a Company |
|
Year ID |
4-digit year i.e. 2023 |
A single year for which the tax information is displayed. A range of years is not allowed. |
Employee Name |
Type name or leave "%" for all |
|
SIN |
numeric or "%" for all identification numbers |
|
Include Electronic T4 |
True or False |
Determines if you want to view the Electronic ones as well |
Include Instruction Page |
True or False |
Choose if you want the instructions included or not |
- Example of the Instructions (listed at the end of the Report)
Report Fields
Field Name |
Explanation |
Employer’s name |
Your employer's legal name. |
Employee’s name and address |
Your legal name and current address. |
Year |
The taxation year the T4 is issued in. |
Box 10 - Province of employment |
If you worked in more than one Province you will receive multiple T4s, one for every Province you have worked in. |
Box 12 - Social insurance number |
Your Social Insurance Number. |
Box 14 - Employment income - line 101 |
Includes not only your wages but also any vacation, bonuses, and taxable benefits, often a summary of several T4 boxes. |
Box 16 - Employee’s CPP contributions – line 308 |
The amount of Canada Pension Plan (CPP) contributions. |
Box 16A - Employee's second CPP contributions (CPP2) |
For T4 slips filed for calendar year 2024 and after, report the amount of CPP2 contributions you deducted from your employee in box 16A if you enter in box 10 that your employee had a province of employment other than Quebec. |
Box 17 - Employee’s QPP contributions – line 308 |
The amount of Quebec Pension Plan (QPP) contributions. This will only be populated if you worked in Québec. |
Box 17A - Employee's second QPP contributions (QPP2) |
For T4 slips filed for calendar year 2024 and after, report the amount of QPP2 contributions you deducted from your employee in box 17A if you enter in box 10 that your employee worked in the province of Quebec. |
Box 18 - Employee’s EI premiums – line 312 |
The amount of EI premiums. |
Box 20 - RPP contributions – line 207 |
The amount of any Registered Pension Plan contributions. |
Box 22 - Income tax deducted - line 437 |
Total amount deducted from your pay for income tax (Federal and Provincial). |
Box 24 - EI insurable earnings |
The amount of EI insurable earnings. |
Box 26 - CPP/QPP pensionable earnings |
The amount of CPP/QPP pensionable earnings. |
Box 28 - Exempt-Exception |
An X under CPP/QPP, EI, or PPIP indicates that your earnings are exempt from these withholdings. The majority of taxpayers are not exempt, so it will likely be left blank. |
Box 29 - Employment code |
This code only applies to specific situations for CPP like employment agency workers, taxi drivers and barbers or hairdressers, otherwise it will be left blank. |
Box 44 - Union dues – line 212 |
This box contains all union dues collected for this tax year. |
Box - 45 - Employer offered dental benefits |
For calendar year 2023 and after, it is mandatory to indicate whether the employee or any of their family members were eligible, on December 31 of that year, to access any dental care insurance, or coverage of dental services of any kind, that you offered. |
Box 46 - Charitable donations – line 349 |
This box contains any charitable donations made through Payroll. If you made other donations outside the office, the charity must issue you a separate tax receipt. |
Box 50 - RPP or DPSP registration number |
This is your employer’s registration number for a company pension or deferred profit sharing plan. |
Box 52 - Pension adjustment – line 206 |
This is the amount that shows pension contributions that impact the total RRSP amount allowable for the year. |
Box 54 - Employer’s account number |
This is your employer’s business number. |
Box 55 - Employee’s PPIP premiums |
This stands for Provincial Parental Insurance Plan and is only applicable to Québec employees. |
Box 56 - PPIP insurable earnings |
This stands for Provincial Parental Insurance Plan and is only applicable to Québec employees, it shows the insurable earnings for this plan for the year. |
Other Information |
These are additional boxes that can be populated for other amounts not shown elsewhere on the T4 Tax Slip. |
Instruction Page
